Fusion SG-SL123SPG 12" 600 Watt Sub-Woofer Sports Grill Gray

Fusion Signature Series 3i Marine Subwoofers 12" 1400-watt CRGBW Sports Gray Marine Subwoofer

Model: 010-02775-11

• Crystal-clear premium sound quality is suited for the marine environment.


• Water-resistant connectors provide simplified installation and superior protection.


• The rigorously tested marinized design has an IP65 rating.


• Built to last season after season, the Signature Series 3i subwoofers include a supported 3-year warranty.

New, water-resistant connectors now come standard. This makes installation easy and provides superior protection from the harsh marine environment.

Material enhancements and protective engineering maintain the sharp aesthetic appeal of your speakers, year after year.

Any product that bears the Fusion True-Marine seal of assurance has been designed by Fusion to withstand the harshest marine environments season after season and comes with an industry-leading 3-year warranty.

This technology provides exceptional self-dampening, high-fidelity and bass reproduction to give you the most premium onboard listening experience imaginable.

These subwoofers are designed to work optimally with Fusion® stereo systems and amplifiers (sold separately) with custom DSP profiles. This requires the Fusion-Link™ smart-device app for setup.

Specifications

General

Physical dimensions (diameter x depth)
14.02" x 10" (356 x 254 mm)

Weight
24.1 lbs (10.93 kg)

Water and dust rating
IP65

Peak power (Watts)
1400 watts

RMS power rating (watts)
700 WATTS

Sensitivity (1 watt @ 1 metre)
86 dB

Magnetic structure
114 OZ

Frequency response
20 Hz—2 kHz

Nominal impedance
4 ohm

Recommended amplifier power (watts RMS)
200-1000 watts

LED lighting
yes, CRGBW (sports style with LED models only)

LED supply voltage
10.8—16 VDC (sports style with LED models only)

LED load current @14.4 VDC (max)
300 mA (sports style with LED models only)

Operating temperature range
32—122 degrees F (0—50 degrees C)

Voice coil diameter
4"

Cone material
Polypropylene cone with rubber surround

Compass-safe distance
181" (460 cm)

Subwoofer connection
Flying lead with water-resistant 2-way connector, 5.9" (150 mm)

LED connection (sports style with LED models only)
Flying lead with water-resistant 6-way connector, 5.9" (150 mm)

Warranty
3 years

Mounting Dimensions

Mounting diameter clearance
12.05" (306 mm)

Mounting depth clearance
8.15" (207 mm)

Optimum enclosure recommendations

Sealed enclosure volume (fully filled with absorption material)
2.12 cubic ft (60 L)

Ported (vented) enclosure volume (lined with absorption material)
8.83 cubic ft (250 L)

Port diameter
4" (101.6 mm)

Port length
5" (127 mm)

What's in the Box:

• Signature Series 3i Marine Subwoofers 12" 1400-watt CRGBW Sports Gray Marine Subwoofer


• 6 Phillips stainless steel mounting screws, 4.8 mm x 50 mm (10 gauge x 2")


• Water-resistant cable assembly with 2-pin connector (5.9" (150 mm))


• Documentation
